FBS-10MCR2-AC

6 points 24VDC digital input (2 points high speed 200KHz, 2 points medium speed 20KHz, 2 points medium speed total 5KHz); 4 points relay
or transistor output (2 points high speed 200KHz, 2 points medium speed 20KHz); 1 RS232 or USB port (expandable up to 5); built-in RTC; I/
O is not expandable

FBs-10MC◇Δ–◎

1. ◇：R ― Relay output；T ― Transistor SINK(NPN) output
J ― Transistor SOURCE (PNP) output

2. Δ：2 ― built-in RS232 port；U ― built-in USB port (non-standard)

3. ◎：AC ― 100~240VAC power supply
D12 ― 12VDC power supply
D24 ― 24VDC power supply

4. The unmarked frequencies of Digital Input (DI) or
Digital Output (DO) are low speed.
